Superlift 6" Basic Lift Kit

Superlift's 6 inch lift kit for the 2015-2022 Chevy Colorado and GMC Canyon is the perfect way to add height to your Colorado/Canyon to fit those larger tires and drastically change the appearance for the better. Superlift Suspension intentionally over-builds our suspension kits to be the best. Our uniquely engineered design adds strength and durability and has bonus features that others do not offer.

Superlift's geometry, from steering timing and linkage angles to driveshaft and CV axle operating angles, yields optimal component service life and exceptional drivability. Our Lower Control arm cross-members are true to their height and are a one-piece, full-width, high-clearance design made of .25" steel plate. Front differential mounts secure the front axle housing unlike any kit on the market today. This kit moves the front axle mounts to our HD crossmembers providing more strength and prevents axle bind.

This kit includes front knuckles, front strut extensions, cross-members, a rear block and u-bolt kit and rear shocks. All require parts are included to make sure your Colorado or Canyon performs in all conditions.

Features:

HD - Plate Crossmembers
HD Axle mounts
Cast steering knuckles
Fabricated rear lift blocks

Benefits:

Retains OEM caster and camber alignment specifications
Maintains ride quality and handling characteristics
Aligns to OEM Specifications
Designed using original Equipment (OE) CAD data for accuracy
Corrects Front to rear Factory rake for a more level stance

NOTES -IMPORTANT

Fits both gas and diesel engines
Requires minor cutting and drilling.
Does NOT fit ZR2 models
Factory wheels will NOT work.
Highly recommended that aftermarket wheels be hub-centric

Tire	Wheel	Backspacing	Offset
33 x 12.50R17	17 x 8.5	-	0
285/65/R18	18 x 9	-	0
285/55/R20	18 x 9	-	0

IMPORTANT DISCLAIMER: The provided tire/wheel fitments are approximate. Actual dimensions of a given tire size can vary considerably from one brand to another. Manufacturers' wheel offset and backspacing measurement points are not always consistent. Backspacing greatly impacts tire-to-fender clearance when turning. Wheel width and backspacing influence whether the tires protrude past the fenders, and to what extent. Considering these IMPORTANT factors, we recommend that you fit-check your tire/wheel selection prior to purchasing.
