Superlift 6" Basic Lift Kit

Features:

Replacement knuckles yield best possible alignment specs. Front track width is not increased and factory turning radius is retained.
Front lower control arm crossmembers laser cut from 3/16" material.
Belly pan, constructed of 1/4" material, connects crossmembers and protects differential.
Front anti-sway bar link extensions retain factory "service for life" links.
New Superide Dual Rate rear coil springs provide ideal ride, handling and load carrying capability.
New bracketry relocates factory rear 4-link points, anti-sway bar links, brake lines and track bar.
New rear compression travel-stop brackets.
Rear shock options include Superlift or Bilstein.
Installs easily with only slight trimming and no exhaust or driveshaft modifications.
Compatible with Dodge's Electronic Stability Program.

NOTE: Will not fit Short Bed Standard Cab models due to rear driveline vibration.
NOTE: The TRX factory ride height is approximately 1" taller than the standard Ram. The part # K116 is not recommended for use on the TRX models due to possible alignment issues and CV shaft vibration caused by the additional lift. Consider our 4" lift system (K114) for about 5" of lift or the K116B with the height adjustable Bilstein front struts. Set the snap ring in the center groove of the strut to achieve proper ride height.

Tire	Wheel	Backspacing	Offset
37 x 12.5	18 x 9	4.25 - 5	-
37 x 12.5	20 x 9	5	-

IMPORTANT DISCLAIMER: The provided tire/wheel fitments are approximate. Actual dimensions of a given tire size can vary considerably from one brand to another. Manufacturers' wheel offset and backspacing measurement points are not always consistent. Backspacing greatly impacts tire-to-fender clearance when turning. Wheel width and backspacing influence whether the tires protrude past the fenders, and to what extent. Considering these IMPORTANT factors, we recommend that you fit-check your tire/wheel selection prior to purchasing.
