SpitzLift Truck Bed Pedestal Crane
Description
The SpitzLift Truck Bed Pedestal Crane will help you get the job done in no time with its 12V DC powered 4 foot crane, with a 900 lb. lift rating. This crane is designed to mount on the right side of the truck bed floor using the provided pedestal mount and hardware. The crane itself is lightweight so you can easily lift it up off the 26" pedestal mount if needed. Removing a pin allows the crane to fold up for storage.
This package includes everything you need to install and use this crane for you next job. SpitzLift backs their cranes with a three year warranty, and the DC hoist and strap comes with a one year warranty. They do offer a recertification program that you can read about under the warranty section below. SpitzLift is proudly made in the USA and meets your ASME and OSHA requirements. Made using top quality materials and workmanship, you can be assured these products are built to last.
Features
- Installs on the right (passenger) side of the truck bed floor
- Constructed from aluminum and steel w/ powder coat and anodized finish
- 900 lb. load capacity
- ASME and OSHA compliant
- 4 ft. crane weighs approximately 40 lbs.
- Total install weight is approximately 71 lbs.
- Comes pre-assembled and load-test certified
- Lift speed: 22.5 ft./min.
- Crane rotates 360 degrees
- Power requirements: 12V DC, 70 Amps
- Strap: 20' mil-spec webbing w/ 1.25 ton hook w/ latch
- Comes w/ pedestal mount and hardware
- Easy to remove crane from pedestal mount and fold away
- Made in the USA
- 3 year limited warranty
Installation
Installation of the SpitzLift Truck Bed Pedestal Crane is fairly involved, professional installation is recommended.
However, you can do it yourself but it may require tools that most people don't have readily available. Cutting into the truck's bed is needed and properly running the supplied wiring is needed. Minor drilling is needed.
Warranty
SpitzLift offers a three-year standard warranty on all our cranes.
AC/DC hoists and straps come with a one-year warranty.
The robust design of SpitzLift cranes makes certain our products have a long life cycle so the ROI that pays for itself multiple times. There are SpitzLift cranes in use today that have been in the field for over fifteen years without failure. This speaks to the exceptional engineering of our products and the high quality of the materials we use to build our cranes.
Recertification Program:
SpitzLift recommends all their cranes are recertified every 24 months to ensure SpitzLift equipment continues to function according to their specifications and continues to meet all safety standards.
Service includes:
Replacement of primary wearable parts
Inspection of structural components
Stress test conducted
SpitzLift provides all supporting recertification documents. Recertification extends the warranty of SpitzLift products another 2 years.
Ship cranes to:
SpitzLift Manufacturing
5644 Kearny Mesa Rd. Ste. H/M
San Diego, CA 92111.
To make certain that your products are OEM compliant within the 24* month re-certification window, contact us at recertification@spitzlift.com.
*Based on type of usage, SpitzLift reserves the right to reduce the re-certification timeline.
